Core strengths

1. Due to the control of feeding form and feeding tension, labor is saved;

2. Due to the breakthrough improvement in overall structure and transmission principle compared to traditional rolling machines, the problem of bubbles generated during the silicone rolling process has been effectively solved, with an efficiency increase of 2-3 times, energy savings of 50-90%, and smaller thickness errors (+/-0.015mm)

On this basis, our company has developed a series of products tailored to different customer needs, including full screen display (real-time monitoring and display of roller speed and gap, with a display accuracy of 0.01mm), electrically adjustable full screen display (real-time monitoring and display of roller speed and gap, electrically adjustable roller gap, with a display accuracy of 0.01mm), and fully computer-controlled (setting roller speed and gap through microcomputer PLC and touch human-machine interface, and real-time monitoring and display, automatically adjusting roller gap, with a display accuracy of 0.01mm)

4. In response to customer requirements, we have developed a fully computer-controlled thermal conductive silicone rolling machine that is more suitable for thermal conductive silicone due to its low tensile strength, high viscosity, and easy to stick rollers. The machine uses a microcomputer PLC and a touch based human-machine interface to set the speed and gap of each roller, and monitors and displays them in real time. The gap between each roller is automatically adjusted with a display accuracy of 0.01mm. The rollers have undergone special treatment (coated with a dense fluorine-containing coating similar to a non stick pan while ensuring high hardness) and are non stick (including high viscosity tape), bringing good news to thermal conductive silicone manufacturers

feature

Basic feeding form: Integrated feeding base, easy to operate, small footprint.

Material release control system: using magnetic powder brakes combined with tension controllers to achieve automatic tension control and save labor.

Main transmission part: AC frequency conversion dedicated motor is used in combination with frequency converter as the rolling power transmission. The speed of each roller is independently controlled, which can adapt to the efficient production of products with different thicknesses, ensure product quality, and save 50-90% electricity.

Roller cooling device: using a rotary joint to introduce cooling water to maintain the working temperature of the roller, ensuring the service life and machine accuracy of the roller.

Automatic meter counting device: It adopts an automatic meter counting device and can be set in two sections to accurately control the rolling length.

Mechanical Specifications

Mechanical manufacturing width: 0.63M-1M

Maximum discharge diameter: 600mm

Inner diameter of discharge tube: 1 "; -3"

Maximum roller distance: 6mm (can be increased to 15mm according to customer requirements)

Maximum output thickness: 5mm (can be increased to 10mm according to customer requirements)

Maximum operating speed: 15m/min

Film release accuracy error: ± 0.015mm
