The wire and cable extrusion granulation production line is selected from Guangdong Lina, a manufacturer of wire and cable extrusion granulation production lines with nearly 20 years of experience. It has a processing base of 30000 square meters, one Lina Technology Park, and three branch factories. Over the years, we have accumulated rich technical experience and over 4000 successful cases.

Wire and cable extrusion granulation production line

The Lina wire and cable extrusion granulation production line is a complete production line that combines plastic refining (internal mixing machine, open mixing machine combined plastic refining), followed by extrusion granulation, cooling, screening, and finished product packaging. Cable products are widely used in countless fields, and most require granulation equipment for post-processing in a granular manner. The production process required for different products also varies. After understanding the performance of the customer's materials, Lina can adjust according to their material properties and configure equipment that suits you.

Characteristics of wire and cable extrusion granulation production line

1. It has control functions such as whole unit process interlocking, sound and light fault alarm, and quick locking of fault points. All materials in contact with the unit are made of stainless steel, with attention to detail, completeness, reliability, energy saving, and durability;

2. The precision of the temperature control system ensures the sensitivity of materials to temperature;

3. The feeding system of the extruder adopts a heater and a reversing device combined with the main screw reversing device to solve the problems of power outage, material jamming, and color cleaning;

4. Especially the use of foreign technology for the material barrel and mold head to ensure and control the risk of personnel explosion caused by uncontrollable pressure of the mold head;

5. The combination of dual link forced feeding system and single screw technology not only meets the high requirements of materials for secondary continuous high mixing, but also solves the labor and time consumption of traditional block crushing, and improves the enterprise image of production capacity, environmental protection, and automated continuous operation;

6. After being combined with an internal mixer and an open mixer, it integrates plastic refining, extrusion granulation, cooling, screening, and finished product packaging into a complete production line. According to the characteristics that different materials are easy to foam in the extrusion environment with unstable temperature, the unit makes a special design for the screw structure of the main machine barrel. The heating system, circulating water cooling system, air cooling system and spray cooling system are combined with a set of temperature measurement and control circuits with high sensitivity, which can accurately control the extrusion temperature, especially those with foreign technology; Explosion proof mold head; The device has been filled in; Safety hazards "; The blank space effectively overcomes the foaming and color difference caused by different materials during the extrusion process, resulting in uniform particle size, good appearance, and superior quality of the finished product. The unit adopts variable frequency speed regulation technology to save energy and control output; Stable operational performance and high production efficiency, widely applicable to plastic granulation production lines;

8. Integrating mixing, lifting, feeding, extrusion, air-cooled cutting/water-cooled cutting, and air-cooled cooling, achieving automated continuous operation and high production efficiency;

9. The mixing, feeding, and extrusion sections can be heated using electric heating, steam heating, or oil circulation heating technology according to the customer's choice, based on their temperature control requirements;

10. The mixer adopts the technology of "four sided synchronous wear-resistant mixing", which has high efficiency, low energy consumption, sufficient plasticization, and uniform dispersion;

11. The feeding device adopts the technology of our company's "conical twin-screw feeding device". Can assist in the mixing of mixed materials and forcibly feed the single screw extruder to improve granulation efficiency and quality;

12. The drive of both twin-screw and single screw adopts AC frequency conversion technology, which can meet various process technology requirements;

13. The front part of the machine head adopts a hydraulic quick screen changing device, which saves time and effort;

14. The granulator adopts a rotary blade and a fine adjustment device for air-cooled hot cutting of granules;

15. The cooling of granular materials is achieved through the use of cyclone separators for transportation and drum type cooling machines or disc type vibrating screens;

16. The electronic control system adopts PLC, visual interface and frequency conversion technology to achieve full automation control.

Guangdong Lina Industrial Co., Ltd. is a professional manufacturer of customized wire and cable extrusion granulation production lines. We specialize in research and development, design, and sales of silicone wire extruders, PTFE wire extruders, rubber wire extruders, BV wire extruders, and other special material extruders. Our company's wire and cable extrusion equipment is widely used in the production of automotive cables, electronic cables, power cables, data cables, network cables, telephone cables, electrical wiring, headphone cables, audio cables, video cables, civilian cables, control cables, etc BV、BW、BVR、RV、RW、 Security cables, low smoke, halogen-free, flame-retardant and environmentally friendly building wiring, power cables, cross-linked polyethylene (XLPE) cables, new energy charging station cables, computer cables, communication cables, coaxial cables, silicone wires, silicone braided wires, silicone heating wires, PTFE wires and other special wires and cables.
