Dispersion Kneader Machine designed to mix and knead materials such as polymers, rubber compounds, adhesives, and various chemicals to achieve uniformity and consistency in the final product.

Here's how it typically works:
Chamber: The Dispersion Kneader Machine consists of a closed chamber, usually cylindrical in shape, where the mixing process takes place.
Rotating Blades: Inside the chamber, there are rotors with intermeshing blades or sigma arms. These blades rotate at different speeds and directions to knead and mix the materials thoroughly.
Material Feeding: Raw materials, including polymer compounds, additives, fillers, and other ingredients, are fed into the chamber. The Dispersion Kneader may have provisions for adding materials manually or automatically.
Mixing Process: Once the materials are inside the chamber, the rotors start rotating, causing the blades to knead and mix the materials intensely. The action of the blades creates shear forces, which help in breaking down the materials and dispersing them uniformly throughout the mixture.
Heating and Cooling: Some Dispersion Kneader come with heating or cooling systems to control the temperature of the mixture during the mixing process. This is crucial for certain applications where temperature control is necessary.
Discharge: After the mixing process is complete, the mixture is discharged from the chamber. Depending on the design of the machine, the discharge may be manual or automated.
Dispersion Kneader Machine offer several advantages over other mixing methods, including:
Efficient mixing of highly viscous materials.
Uniform dispersion of additives and fillers.
Reduced mixing time compared to traditional mixing methods.
Better control over mixing parameters such as temperature and shear forces.
Minimized risk of material degradation or overheating.
The Dispersion Kneader Machine are widely used in industries such as rubber manufacturing, plastic compounding, pharmaceuticals, and food processing, where consistent and uniform mixing of materials is essential for the quality of the final products.

Item	Specification	remarks
Type	Pressurized Flipping Type
Mixing Capacity	1.5 liter
Production Yield	1.0-1.5 KG per time	Subject to the proportion of material and dispersion requirements.
Main Motor Power	3.7 KW
Flipping Method	Hydraulic type
Flipping Angle	110°
Temperature Control	Heating or/and cooling	Electric/oil/steam heating and circulating water cooling.
Weight	About 800 KG
Dimensions	About 1600*900*1900 mm
